Yacht Summary

X-43

Sold

Standard Specification

DesignerNiels Jeppesen
Hull Length12.93 m42'5"
Waterline Length11.45 m37'7"
Beam (max)3.97 m13'0"
Draft2.20 m7'3"
Ballast - Std3,700 kg8,157 lbs
Displacement - Light8,600 kg18,960 lbs

Standard X-43 brochure

Details

Exterior Details

Hull

  • Built in sandwich with polyester resin n construction with structural foam core, Bi-directional and uni directional E-glass
  • Steel frame – hot galvanized, high strength, laminated into hull absorb all loads from keel, mast and rigging
  • Outer surface of white hull Gelcoat with 3 blue waterlines
  • Single point hoist for easy and safe lifting and launching of the yacht
  • Hull recessed portlights - (6 pcs)
  • Deep keel 2.50m with heavy bulb draftmade of antimony hardened lead heavy bulb bolted and glued to cast iron fin
  • Keel securely bolted to reinforced keel structure
  • Rudder stock mounted with needle and self aligning bearings
  • Steering system with from « JEFA » , with gear box directly mounted on the sector of helme
  • Carbon steering wheel 1,70 m
  • New epoxy bottom coating and Antifoulling NAUTIX A4 in July 2023

Deck

  • Side deck, cockpit sole seats with teak.
  • Anchor locker - drained area with 12 V 1000 W LOFRANS PROJECT 1000 electric windlass
  • DELTA anchor16 kg
  • Gas spring fitted to forward and both aft cockpit lockers
  • Moorings cleats in stainless steel lounted fore, aft and amidships,
  • Bathing ladder in stainless steel integrated in transom platform
  • Stainless Steel handrails on coachroof
  • Sprayhood on stainless steel arch
  • Bimini with stainless steel frame 2022

Sail Handling

  • Primary ANDERSEN 2 speeds ST 52 x 2
  • German mainsheet system Winches ANDERSEN ST 46.2 x 2
  • Halyards winches ANDERSEN ST 46.2 x 2
  • Spinlock Jammer
  • "German Main Sheet" under deck
  • Maisheet and genoa travellers
  • Spinnaker deck equipment with carbon spinnaker boom
  • Carbon wheel

Sails

  • Elvström Genoa 2017 (DCX grey taffeta)
  • Sails by Delta Voiles
  • Full batten Mylar mainsail
  • Furling Mylar Genoa 132%
  • Mylar Solent 106%
  • Code 0 on Profurl furler
  • Light Spinnaker 0.5 oz
  • Medium Spinnaker 0.9oz
  • Spinnaker snuffer 2011
  • Lazy bag Dralon 2021

Mast & Rigging

  • NORDIC MAST Carbon mast and boom fractional double spreaders keel stepped mast,
  • Discontinuous rod rigging with rod turnbuckles ,
  • Telescopic vang with outer purchase block system
  • Split backstay fitted with hydraulic NAVTEC backstay adjuster
  • PROFURL headsail furler with
  • Spinnaker deck equipment with carbon spinnaker boom

Keel

  • Deep keel 2.50 m with heavy bulb

Accommodation

  • 3 cabines Modern layout, teak wood

Systems

Engine

  • VOLVO D2-55 KP
  • FLEXOFOLD folding propeller, 2-bladed bronze for S-drive
  • Gasoil tank 130 L
  • Fullly serviced in 2021 with new rubber saildrive
  • Service 2023

Plumbing

  • Seacocks and through hull fittings are bronze ball and flush mounted
  • Fresh water stainless steel tank (380 litre)
  • Hot water tank Isotherm 19 l. Tank can be heated either by main engine or immersion heater connected to shore power
  • Pressurized freshwater system for hot and cold water throughout yacht
  • Deck shower hot and cold
  • Fridge top opened 163 l built in Isotherm SP, accumulator plate and compressor
  • Gimballed Gas cooker - 3 burner Eno GASCOGNEcooker with oven

Electrical

  • Main switch board with 27 automatic fuses and 3 analogue VDO meters for fuel, water and battery voltage
  • Gel services batteries 5 x 110 amp
  • Separate engine spiral-cell battery
  • Shore power installation with shore power inlet mounted in cockpit
  • AC distribution box with circuit breaker/10A fuse, 230V AC socket and switches for hot water heater and battery charger
  • MASTERVOLT automatic battery charger 12V/25 Ah

Electronics

  • NKE electronics
  • Gyropilot NKE
  • Sensors for log – speed – depth – wind
  • Multi display at the chart table
  • Multi display TL25 on mast bracket
  • NAVTEX FURUNO at the chart table
  • VHF
