Details

Exterior Details

Hull

• Hull is vacuum epoxy infused, sandwich construction with structural fiberglass
• Hull in dark grey (RAL 7021) gelcoat with the 3 distinctive X-Yachts' waterlines in white gelcoat
• Bottom treatment from yard (3x epoxy primer and 3x antifouling)
• Antifouling is scheduled to be freshly applied spring 2022 prior to launching
• Stainless steel chafing strip along length of hull
• Transom door with teak
• Bowsprit in carbonfiber

Deck

• Teak in cockpit, on side decks and on coachroof
• Large dry saillocker in the bow of the boat
• Anchor locker with electrical anchor winch
• 16kg Delta anchor with 50m anchor chain
• Additional mooring cleats midships
• 2x Harken Performa 46 halyard winches
• Port side halyard winch is electric
• 2x Harken Performa 50 genoa winches
• 2x Harken Performa 46 mainsheet winches
• Gennaker deck gear with all necessary blocks and sheets
• Sprayhood, foldable into recess in deck, in grey canvas
• Cockpit shower
• Cockpit table in teak on aluminium legs (removable)
• Black composite steering wheels
• Medium consoles at steering wheels (for plotter and instruments) in dark grey
• Ritchie magnetic compass in console at steering wheel
• Fusion speakers in cockpit (for stereo

Sails

• Elvstrom Sails mainsail in EPEX Platinum membrane, fully battened and with 2 reefs
• Quantum Sails 106% furling jib in Fusuon laminate, with UV-cover (2021)
• North Sails A3 gennaker in Norlon 75 cloth, with snuffer
• Mainsail cover in grey
• Genoa cover in grey

Mast & Rigging

• Custom designed aluminum mast, boom and vang for X4.3 by Seldén
• Rod rigging as standard for all standing rigging
• Hydraulic backstay adjuster
• Furlex genoa furling system
• All halyards and sheets in dyneema
• Combined LED 3-colour/anchor light in top of mast
• Combined LED deck/steaming light on forward face of mast
• Lazy jacks system for handling the mainsail
• Rail for spinnaker pole adjustment on front face of mast
• Second spinnaker halyard
• Additional topping lift halyard for spinnaker pole

Accommodation

Interior

• 3-cabin/2-heads lay-out
• Full interior crafted with selected Nordic oak veneer
• Eberspächer heating system with vents in each cabin
• OceanAir curtain system for all hatches and coachroof windows
• Additional LED downlighting below cabinets in saloon
• 2x red LED nightlights
• Spring mattrasses in forward cabin
• Additonal cabinet sections along hull in forward cabin
• Electrical toilet in aft heads
• 3-burner stove with oven in galley
• Additional front-loading refrigerator
• Nespresso machine in dedicated cabinet section
• Fusion MS-AV750i marine stereo with speakers in saloon

Systems

Engine

• Upgrade to 3-blade folding propellor

Electrical

• Upgrade of service battery bank to 3x 110Ah AGM battery
• Upgrade of standard battery charger to larger 50A capacity
• Additional 12V socket in cockpit
• Dedicated inverter for supply of 230V out of the batteries (2021)

Electronics

• B&G Triton2 package, consisting of:
• - 4x Triton2 display above sliding hatch
• - ZG100 GPS antenna
• - transducers for speed, depth and wind
• B&G autopilot system:
• - NAC-3 pilot computer
• - Precision9 electronic compass
• - 1x Triton2 control panel in console at steering wheel
• - 1x Triton2 display in console at steering wheel
• - linear hydraulic drive mounted on rudder quadrant
• B&G Zeus3 9" GPS/plotter in console at steering wheel
• B&G V90 DSC-D VHF with handser and speaker
• B&G H50 wireless handset for VHF, with charging station in cockpit
• B&G nAIS400 transceiver with NSPL-500 antenna splitter

Thrusters

• MaxPower Compact Retract bowthruste

Additional Information

• Mooring lines
• 4x fender
• 3x Harken winch handle
