Details

Exterior Details

Hull

• Hull epoxy infused in female moulds for optimum consolidation and high quality surface finish
• Hull liner in bi-directional and unidirectional E-Glass and locally reinforced with unidirectional carbon fibre
• Solid laminate in high stress areas in way of keel top, sail drive and rudder
• Outer surface of hull in white gel coat (RAL 9010) and the waterlines and sheer stripe in dark blue (Ral
• 5011)
• Single point hoist for easy and safe lifting and launching of the yacht - lifting strop is optiona

Deck

• Deck covered white Gelcoat (RAL 9010)
• Xhite non skid on the deck
• Teak on cockpit seat

Sail Handling

• 2 Genoa primary winches 2 x HARKEN 46.2 ST instead of 40 PTA
• Assymetrical deckfittting
• Inhaulers

Sails

• Racing sails + Cruising

Mast & Rigging

• JOHN MAST 2 spreaders with rod rigging
• Tuff luff
• Headsail furler (not installed)
• Dynnema running rigging

Keel

• Standard 1.90 m “T” keel
• Cast iron keel fin and antimony hardened lead bulb
• Bolted keel on carbon reinforced frame

Systems

Engine

• 3 cylinder 20 HP diesel YANMAR 3 YM 20
• Engine on rubber suspensions with S-drive installation, freshwater cooled
• Special engine compartment with sound insulation ensures low noise level in yacht
• Engine easily accessible for service by fully remoavble, insulated GRP section
• Folding propeller, 2-bladed bronze for S-drive
• Engine control panel and throttle/gear lever placed in starboard cockpit coaming
• Fuel tank in aluminium. Analogue level gauge, filter with water separator and shut-off valve and deck fill
• (50 litre

Plumbing

• Galley, high gloss white composite moulding with stainless steel sink and single lever mixer tap
• Integrated space/shelves for crockery/pot/pan in the front of the galley
• Top cupboard outboard with smoke coloured 5 mm sliding Plexi doors
• Gimballed gas cooker -

Electrical

• 12V DC system throughout yacht
• X-Yachts main switch board with automatic fuses and 2 analogue meters for fuel level and battery voltage
• level
• 12V DC system for main engine installation
• AGM engine battery (70 Ah, 12V) mounted near main engine for starting of engine.
• Engine battery is charged by the engine
• 5 reading lights fitted on bulkheads throughout the boat
• 1 chart table light on a flexible arm by the nav statio

Electronics

• Mast foot support with 3 displays + race master
• Electronic TACKTIK with speed, deepth , wind sensor
• VHF
• NMEA interface with GPS antenna
• Raymarine autopilot with linear drive and P70* control box
• Cockpit speaker
